This solenoid-operated 2-way, 2-position cartridge is a direct-acting, balanced spool pilot valve used to pilot other full-flow valves. The valve is available in either a normally open or normally closed configuration.

This cartridge can be installed directly into a cavity in the end of many of Sun’s pilot operated and ventable valves to provide integrated pilot control.

• Model DAAL integrates the same coil, connector, and manual override options that are currently available on Series 1 valves. The DAAL is interchangeable with the DAAA except for the external coil dimensions and higher coil wattage.
• The solenoid tube assembly is fatigue rated for 5000 psi (350 bar) service.
• This valve is direct actuated and requires no minimum hydraulic pressure for operation.
